Features

■Layout principle of integral column or double columns, double wheelheads(single wheelhead) and saddle movement with vertical spindle and rotary table.

■Table adopts hydrostatic guideway and is driven by AC Servomotor.

■Independent intellectual property right for wheelhead, the grinding wheelhead adopts imported precision bearings. The wheelehead spindle is equipped with cooling water temperature control device.

■Machine equipped with double wheelheads has eleven control axes. All feed axes adopt Heidenhan grating scale for full-closed loop control (option).

■The workpieces are clamped vertically for grinding. Multi-stage combined processing in one-time clamping.
