Features

■Cross table layout principle, compact structure of column and wheelhead, high vertical feed sensitivity.

■Roller guideways for table cross movement, cross feed controlled by AC frequency motor with stepless speed regulation to realize fine intermittent feed and continuous movement.

■Reversible and variable vane pump driven for table longitudinal movement, closed hydraulic system

■Throttle-hole type hydrostatic bearings for wheelhead spindle

■Auto grinding wheel dresser with stepless dressing speed, dressing path parallels with the table surface, rough and fine dressing can be realized.
